CNMC-450
Hightop-CNMC
Application Examples: automobile parts, medical devices, precision instruments, machinery, electronic products, fragile products, lighting products, sanitary products, household articles, insulation works, vacuum cup, refrigerator, water heaters, sterilizer, building board, sports goods, toys, carpet, mattress, etc.
No
| Item | Technical parameter |
1 | Foam application | Flexible foam |
2 | Raw material viscosity(22℃) | POL ~3000CPS ISO ~1000MPas |
3 | Injection output | 80-450g/s |
4 | Mixing ratio range | 100:30~60 |
5 | Mixing head | 2800-5000rpm, forced dynamic mixing |
6 | Tank volume | 120L |
7 | Metering pump | A pump: GPA-40 Type ; B Pump:GPA-25 Type |
8 | Compressed air needed | Dry, oil free, P:0.6-0.8MPa Q:600NL/min(Customer-owned)
|
9 | Temperature control system | Heat:2×3Kw |
10 | Input power | Three-phase ,220V,60HZ |
11 | Rated power | About 15KW |
12 | Swing arm | 1.5m from cabinet to injection head |
13 | Volume | 3700(L)*1250(W)*2500(H)mm, swing arm included |
14 | Color( customizable) | Cream-colored/orange/deep sea blue |
15 | Weight | About 1000Kg |
Application Examples: automobile parts, medical devices, precision instruments, machinery, electronic products, fragile products, lighting products, sanitary products, household articles, insulation works, vacuum cup, refrigerator, water heaters, sterilizer, building board, sports goods, toys, carpet, mattress, etc.
No
| Item | Technical parameter |
1 | Foam application | Flexible foam |
2 | Raw material viscosity(22℃) | POL ~3000CPS ISO ~1000MPas |
3 | Injection output | 80-450g/s |
4 | Mixing ratio range | 100:30~60 |
5 | Mixing head | 2800-5000rpm, forced dynamic mixing |
6 | Tank volume | 120L |
7 | Metering pump | A pump: GPA-40 Type ; B Pump:GPA-25 Type |
8 | Compressed air needed | Dry, oil free, P:0.6-0.8MPa Q:600NL/min(Customer-owned)
|
9 | Temperature control system | Heat:2×3Kw |
10 | Input power | Three-phase ,220V,60HZ |
11 | Rated power | About 15KW |
12 | Swing arm | 1.5m from cabinet to injection head |
13 | Volume | 3700(L)*1250(W)*2500(H)mm, swing arm included |
14 | Color( customizable) | Cream-colored/orange/deep sea blue |
15 | Weight | About 1000Kg |
